Official Swap Trick Support Thread

racketboy - Jun 14, 2004

1

2

3

Next

		racketboy	Jun 14, 2004
		Thought we should start an official Swap Trick info and support thread and sticky it. Maybe we could merge some existing threads in here? To start, here are links to our guides in the Help section (for the newbies that don't know where to look): Swap Info... Swap with Model 2 Saturn... Swap with Pro Action Replay... Swap with Model 2 Video (divx)...

		TJax69	Sep 6, 2004
		It appears as though none of the above links work

		racketboy	Sep 6, 2004
		fixed. the domain was switched. thanks for the headsup and welcome to SX

		TJax69	Sep 6, 2004
		Glad I could make myself usefull!

		shinshade	Nov 18, 2004
		Is there a picture somewhere which shows what bit you have to tape down? Thanks for the help in advance

		lordofduct	Nov 18, 2004
		well its a crappy pic... but you see that thing my arrow is pointing at? its a switch, tape it down!

		shinshade	Nov 18, 2004
		Thanks for that, Its all working now

		shinshade	Nov 18, 2004
		Another question, If I used the swap trick with the Saturn Satelite or action replay would I be be able to play Import backups?

		lordofduct	Nov 18, 2004
		yes.... also in my opion, the action replay it makes it easier to do the swap trick!

		racketboy	Nov 18, 2004
		As I tell everyone that asks me, every Saturn enthusiast should have a 5-in-1 cart of some sort.

		Zoel	Jan 31, 2005
		Doesn't the swap trick kill your Motor for the lens?

		racketboy	Jan 31, 2005
		Yeah eventually, but some people think it's worth the chance. Also Model 1's are especially hard to mod.

		logicbomb.de	Feb 3, 2005
		Although I'm sure its been covered before, I've found that different certain original Saturn games lend themselves to be easier to use in the Swap Trick than others. For example, I was able to perform the swap trick successfully on my second try using the extended swap method, (boot with CDr until audio tracks are recognized, then reset and swap) usind disc one of the game "D" on a model 2 Saturn. I've never had any success swapping using NiGHTS as on original, but I really only tried less than 5 timesm cos it kinda hurts knowing that you're damaging the motor each time you swap.... BTW, I was able to run a back up of Radiant Sivergun using the swap trick WITHOUT an import cart but I'm not 100% sure that it was an unpatched image. I'll take a look at the Saturn header to verify the country code to see if has been changed to run on an NTSC-U Saturn

		[rocketbeetle]	May 23, 2005
		Hi. It's been a while since I visited this great site. A year ago I posted some info about an easy mod that makes disk-swapping a lot easier and less destructive. But I notice that it hasn't gotten the attention that it deseves. I have now taken a couple of better images and made a small video to show how great this mod works. [attachmentid=1289] [attachmentid=1290] [attachmentid=1293] And you don't have to worry about killing the motor for the lens... or anything else for that matter. Because the power is cut while you do the swap. I have used this mod for a little more than a year and it works perfectly every single time... The original post can be found here: http://forums.segaxtreme.net/showthread.php?t=9740... As you can see in the video, the switch I use is just taped on top of my Saturn... I don't want to drill a hole... But ofcourse you can make the switch look much nicer than that. Hm.. maybe I should mention that my Saturn is a Model 1 with modelnr:MK-80200-50. Ofcourse I do not take responsibility for any harm that you may cause to your Saturn if you try this.... But it sure is worth a try.. I had some problems attaching the video... I had to rename it.. If it doesn't work try to save it and rename it to "swap.avi"... its coded with ffdshow xvid...

		Elin	May 26, 2005
		Ah, I've been having a little trouble with the swap trick on my Model 1 PAL Saturn recently... Not because it's particularly difficult, I can pull it off most everytime, but all of my backups save Radiant Silvergun halt on the 'Sega' screen. This occurs regardless of whether they are correctly patched to Europe, and only Radiant Silvergun seems to be spared from said problem (despite it allegedly being patched to US... Or so sayeth satconv...). All the backups, including Silvergun, were burned at the same speed, with the same program and the same CD burner. I've tried several different original games as bootdisks, and none seem to help. Originals play fine on my Saturn, as does the aforementioned Radiant Silvergun. I'd conclude that either my CD drive or my Saturn was buggered up were it not for the fact that Radiant Silvergun works just fine. I'm kind of puzzled... So yeah, I'm somewhat at my wits end and sick and tired of making coasters, but since Model 1 Saturns aren't really moddable, there's not really much else I can do as far as backups are concerned... So I came here ^_^ Does anyone have any ideas what could be wrong?

		ExCyber	May 26, 2005
		The behavior you describe seems consistent with swapping from the original to the CD-R too late. Your original needs to be out of the drive before the pickup has finished returning to the center.

		hinders	Jun 16, 2005
		<------------never mind, got it to work--------------->

		kevrohall	Jul 13, 2005
		try more cd that are patched to us then.....or and it's u.s /canada

		Zoel	Jul 26, 2005
		If you can't do the swap trick. Try opening the lid up and do the swap trick by seeing the lens move. when you see the lens move to the back put the real game in , then when goes back to the center put the backup in. I could never do the swap trick until i have to cover open cause i could never time it right. ( i couldn't heard the sound of the motor to well cause i'm little deaf..) So try this trick.

		Virgil	Sep 27, 2005
		I don't think you stop the motor long enough to kill it. A forcefully- halted motort draws lot of watts, and begens to heat up and that's what COULD cause damage. It'll take awile of holding it still for that to happen, because the moter has very little torque. And, with a saturn, it seams as thought the motor cuts out if it's stopped forcefull, likely to prevent damage to the system :lol: and, assuming you don't drag the disc over the laser, ther's no way in hell the swap trick would damage it :banana
